ALL DIMENSIONS ARE APPROXIMATE DUE TO MINOR PART TO PART VARIANCE
Total length (bit clip closed): 213.1mm (8.4")
Total length (bit clip open): 260.0mm (10.2")
Widest point (handle): 35.0mm (1.4")
Shaft length: 82.2mm (3.2")
Weight: 0.34lbs
Couldn't load pickup availability
ALL DIMENSIONS ARE APPROXIMATE DUE TO MINOR PART TO PART VARIANCE
Total length (bit clip closed): 213.1mm (8.4")
Total length (bit clip open): 260.0mm (10.2")
Widest point (handle): 35.0mm (1.4")
Shaft length: 82.2mm (3.2")
Weight: 0.34lbs
Handle, selector, end cap, shoulder ring, bit tube: Triax 1120
Bit clips, slotted spacer, clip retaining pin, ratchet kicker, ratchet transfer cup, black accent ring: Delrin 500
Ratchet retaining clip, ratchet shaft collar: Acetal
Orange accent ring: ABS
Cast ratchet housing: Zinc (ZAMAK 3)
Silver rotating shaft: Passivated 303 stainless steel
Bit clip spline shaft: Passivated 303 stainless steel
Ratchet gear: S2 steel (HRC60 +/- 2)
Ratchet springs: Spring steel 0.35mm gauge
Broach magnet: N52 (5.4N+ pull force)
Ball bearings: Stainless steel
Pawls: K5 steel (HRC 45-50)
The LTT Screwdriver is covered by a limited lifetime warranty against breakage due to defects in materials or workmanship for the usual and customary life of the tool.
The limited lifetime warranty does not cover:
To complete your warranty claim you must send your product to the address provided by our customer service team. Creator Warehouse, Inc. reserves the right to inspect your product to determine if it is subject to this warranty. If we determine that your product is covered by this warranty, we will (at our discretion): (1) repair the product at no charge for labour or parts, (2) replace the product with the same model product, (3) replace the product with a comparable product should your product be discontinued or otherwise unavailable, or (4) provide you with a voucher to be used toward the purchase of other products on LTTStore.com.
In order to make a warranty claim, you must be the original purchaser of the LTT Screwdriver from LTTstore.com or provide a copy of the original proof of purchase.
All MYSTERY COLOR SCREWDRIVER sales are final. We are not able to offer returns or exchanges for this item. Our standard limited lifetime warranty is still available for any functional or assembly issues with this product.
Pricing on this product is due to the limited run of each color - pricing may change on future production runs due to scale.
Add a splash of color to your toolbox with the "currently limited edition" LTT Screwdrivers in a variety of mystery colors! (These may return sometime in the future, but it won't happen soon!)
A "mystery" screwdriver will be a random assortment of colors, NOT a solid color (examples in picture). This may include components from any of our currently available colors - black, red, orange, yellow, green, blue, purple, and pink.
All Solid-Color and MYSTERY COLOR Screwdrivers include a limited edition RGB Screwdriver pin with purchase.
Product information
This is the complete vision of a screwdriver designed for Linus and the whole LTT team. It features a knurled stainless steel shaft with a strong magnet inside, internal storage for 12 "shorty" 20mm bits (or 6 full-sized bits), an in-house designed three-lobe handle for comfort and ergonomics, and a tastefully-embossed LTT logo on the end cap.
The ratchet is based on Megapro's long-standing & reliable design, but has been significantly modified to suit our needs. We reversed the ratchet direction (right for clockwise, left for anti-clockwise), adjusted the spring for lighter back-force which allows you to ratchet-drive even very small screws, and optimized for smoothness and quiet function. It's rated for operation of up to 220 inch-pounds of force.
Our bit storage is another collaboration with Megapro. We utilized their patented bit clip storage design, but adjusted the length of the clips & the size of the total cavity to allow for our smaller, more ergonomic handle.
All external plastics are Triax 1120 - a Nylon and ABS polymer which is great for injection molding parts like ours - for its overall durability and chemical resistance. The only exception is the black "accent ring" on the all black versions, which are made from machined Delrin, and the orange "accent ring" on the black & orange version, which are made from injection molded ABS.
Internal plastics in our ratchet are also made from Delrin for its self-lubricating properties, and our ratchet housing is made from Zinc.
Our industrial-looking black phosphate-coated S2 steel bits are durable and rust resistant.
Standard bit set included with the screwdriver: PH0, PH1, PH2, H2, H2.5, H4, SL2, SL4, SL6, SQ1, SQ2, and our 5x5 Magnet bit (affectionately named "The Screw Retriever") (This was previously listed as a 6x6 magnet bit, but that was incorrect. The size is 5x5mm)
NOTE: Bits are a consumable item and will wear or break down over time. Visual wear to the black phosphate coating is normal and expected.
Other bit sets are available for purchase at https://www.lttstore.com/products/bits
Using patents from Megapro Tools Inc.: 5,265,504 & 7,258,046
WARNING: Not compliant with airport security restrictions in some countries (including but not limited to US and Canada). Verify all security/travel restrictions before traveling with your screwdriver!
